The Environmental Sample Processor (ESP)

Sensors: Underwater Research of the Future (SURF Center)

Mechanical Engineer Doug Pargett and Electrical Engineer Scott Jensen work on integrating the third generation ESP into a long-range autonomous underwater vehicle. Photo: Todd Walsh © MBARI 2014

The MBARI Environmental Sample Processor—the ESP—provides on-site (in situ) collection and analysis of water samples from the ocean, identifying the presence of organisms and/or biological toxins.

The instrument uses an electromechanical fluidic system designed to autonomously collect and filter water samples. Then it either preserves and archives the sample for use after the ESP is recovered or directly applies molecular detection technology to investigate the biology of the sample in near real-time.

Why build an ESP?

Whether trying to identify microorganisms or understand why certain algae produce toxins, analysis typically requires collecting water samples at sea and returning them to a fully equipped laboratory. This can introduce a significant time lag between sample collection and informative results. Additionally, water collection can become very expensive if boats or ships are needed on a regular basis.

Thus in the early 2000s, MBARI initiated the development of the ESP and new techniques to allow the remote application of molecular probe technology. The hope was to provide a “persistent presence” in the ocean, bringing the laboratory to the sea, and thus reaping cost savings in the most expensive part of microbial oceanography—sample collection.

How the ESP Works

The ESP uses a complex water filtration and biochemical assay system to determine the presence and quantity of specific microorganisms.

ESP Web Portal

The Environmental Sample Processor web portal provides near-real time access to the results of molecular assays conducted at sea as well as data on the environmental conditions during sampling.

Genomic sensors

By utilizing cellular-level molecular biology, the ESP can assist multiple areas of oceanographic research and resource management.

Team

Kevin Gomes

Information Engineering Group Lead

John Ryan

Senior Research Specialist
