MARS site description


The Monterey Accelerated Research System (MARS) ocean observatory is located about 891 meters (2,923 feet) below the sea surface. The main science node (and all science experiments to date) are located on Smooth Ridge, about 25 kilometers west-northwest of Monterey.

Location of MARS science node on Smooth Ridge. Image: David Fierstein ©2009 MBARI.


Smooth Ridge is a broad, gently sloping underwater plateau that lies just west of Monterey Bay. It is part of the continental slope—the transition zone between the continental shelf and the abyssal waters farther offshore. Smooth Ridge slopes gradually from about 300 meters depth at the edge of the continental shelf to about 2,000 meters at its western toe. At its upper end, Smooth Ridge narrows to form a 3-km-wide neck. This neck connects with the continental shelf at a depth of about 150 meters.


The eastern and southern edges of Smooth Ridge are actively eroding, and are cut by nearly continuous underwater slope failures. The south edge of Smooth Ridge drops steeply into Monterey Canyon. The active San Gregorio fault runs along northern edge of Smooth Ridge, and crosses the “neck” of the ridge. Both the fault zone and the walls of Monterey Canyon contain many large underwater slope failures. The northwest edge of Smooth Ridge is cut by Cabrillo Canyon. This canyon is not believed to be actively eroding at present, but was probably active during the last glacial period, when sea level was lower.

Most of Smooth Ridge is covered with fine, muddy sediment, with occasional outcrops of harder sediment and carbonate rocks. The fine sediment is at least 5 to 10 meters thick at the MARS observatory site. This mud probably accumulated several million years ago. Geological studies suggest that little, if any sediment is accumulating on Smooth Ridge today.

Physical oceanography

The waters overlying MARS science node are affected by both nearshore processes, such as upwelling, and offshore processes, such as the meanderings of the California Current. Especially during spring and summer, wind-generated upwelling takes place northwest of Monterey Bay, creating surface plumes of cold, nutrient-rich water that flow along shore and across the mouth of the bay. These plumes usually flow east of the MARS site, but help generate surface currents that typically form a counter-clockwise gyre centered over Smooth Ridge. Occasionally upwelled water may be entrained in this gyre and carried out to the MARS site.

At other times of year, water from the California Current or the sub-equatorial Pacific may be carried toward shore and flow across the MARS site. During the winter months, the site may be affected by the northward-flowing Davidson Current. During the summer months, this northward current disappears from the surface waters, but continues to flow at depths of 200 meters or more, and is sometimes known as the California Undercurrent.


Researchers at MBARI have been studying and surveying the seafloor animals on Smooth Ridge since at least 1994. Many of these animals are typical for soft-sediment areas along the continental slope. Different animal communities occur at certain depths. Even at a single depth, denser animal populations or different groupings appear in distinct patches. Several chemosynthetic biological communities are known on Smooth Ridge, mostly along the steep edges to the west and south.

Seafloor animals near the MARS site include sea pens, sea stars, brittle stars, crabs (especially Tanner crabs), snails (especially Neptunia), octopus, and fish (especially rockfish, hagfish, and rattails).
